Awards Winners

The24th award

Japan Vocational Ability Development Association Chairman's Award

Japan Vocational Ability Development Association Chairman's Award

Welding Fabrication

MIWA Industries Ltd.

URL http://www.miwaintec.co.jp/jp/

Quarter Mebius Loop

●Material Type:SUS304 ●Thickness:0.8mm

(L)Mr. Yasunori Sutou, of
NC Engineering Department ,
(C)Mr. Takahiro Miwa, CEO,
(R)Mr. Tomohiko Miwa, Chief of
2nd Production Department

This Quarter Mobius Loop is our 3D version Mobius Loop. A square pipe is twisted a 1/4 and the ends are welded together. The drawing was easily made with 3D CAD, but we couldn’t automatically unfold because the surface was twisted. So we had to make 8 flat surfaces for each 1 degree angle for all 360 degrees, and it was very time consuming.

Also for welding, since a thin sheet was used for twisting easy, we couldn’t weld too deep, and we had to really focus to maintain a square for the entire circumference.

This piece was completed within a specific time frame, in just one-off component which shows the characteristic of our company that specializes in high-mix, low-volume production.

We are very happy to receive such a tremendous award. All of us at the company will strive to improve the skills and continue to manufacture products that will live up to this award.
