System Upgrade

Bi-J （Bending Indicator）

Bi-J Automated bending angle correction system

The Bending Indicator is a high-speed/ high-precision bending sensor for bending machines with AMNC/PC

Specifications

	Angle check range	Angle correction accuracy	Sheet thickness (mm)	Sheet	V-groove width (mm)
Bi-J	90°～150°	±15′【HDS‐NT】	1.0～4.5	SPCC・SECC acid washed material	6～25

Laser Safe

Shut-down device for worker safety

Specifications

	Applicable models
LZS	Can be retrofit to bending machines with AMNC/PC

Work follower series

Liberation from heavy bending work

Specifications

	Sheet thickness (mm)	Work-piece dimensions (mm)	Capacity (kg)/m	Auto follower-up angle
WS-2000	0.5～3.2	300×300～1000×1000	20/0.5m	0～75°
WS-4000		300×300～1000×1800	40/0.5m
WS-7000		300×300～1000×2400	70/0.5m
WFN-150	0.6～6.0	MAX:1250×2500	150	0°/10～70°

NC9-mini

Back gauge & depth control device for RG-Z II

Specifications

	Applicable models	Control method	Control axis	Input system	Feed speed
NC9-mini	RG-25～125	Micro computer	2	D axis: Touch panel playback	D axis: 9 stages (8～600mm/min) L axis: Max.5m/min

Work sensor attachment

Prevents defective dimensions caused by back gauge errors, one type of defective processing of bending products. We have also prepared a work sensor with uneven tips.

Supported models

HDS-NT Series / AMNC/PC_Ver.5or later

Load control

Eliminate material thickness variations, changes in machine with time and machine-dependent differences, and produce the objective angle from the first curve, just by changing the table stop signal from Measure (Position) to Scale (load).

Supported models

HDS-NT Series / AMNC/PC_Ver.5or later

TDS

AMADA's TDS system is a system for detecting material thickness variations as a load change and controlling the D axis. Supports stabilization of the finish angle.

Supported models

HDS-NT Series / AMNC/PC_Ver.5or later

*For Japan domestic market.
For any inquires, please contact local AMADA branch office.
