第36回優秀板金製品技能フェア
単体品の部 全107作品
単体033
技能賞
BOILER BRACKET
Fantauzzi srl (ITALIA)
-
・サイズ: W134,6 × D129.3 × H30 mm
-
・精度: ± 0,1 mm
-
・プログラム時間: 3 分
-
・加工時間: 5 分/個
-
・加工数量: 1 個
-
・材質: AISI 430
-
・板厚: 3 mm
-
・作品種類: 量産品
加工工程
CAD/CAM
レーザ加工
曲げ
アピールポイント
The special feature of the work consists in short bend flange with medium thickness, which forces the use of specific V die (V12).
The part is a boiler bracket for coffee machine, and it requires high precision and low tolerance.
