37th Precision Sheet Metal Technology Fair

Sheet metal parts (121 entries)

360° Viewer

Parts058

Technical Encouragement Award

Interiors Profile

FeCuNi (India)

  • ・Size: W45 x D300 x H25 mm

  • ・Accuracy: ± 0.05 mm

  • ・Programming time: 5 min

  • ・Processing time: 2 min/quantity

  • ・Quantity: 1

  • ・Material: Stainless steel (SUS304)

  • ・Thickness: 0.75 mm

  • ・Type: Production work

Process

  • V Grooving

  • Bending

Strengths

V-grooving followed by bending on the Amada HRB1003 bending machine enables precise, sharp bends in sheet metal by first reducing material thickness along the bend line, allowing for tighter radii and improved accuracy during the bending process.
