Iron round pipe grid (Formative432)
Formative432
Technical Encouragement Award
Iron round pipe grid
山鴻鉄工 株式会社 (Aichi, Japan)
-
・Size: W500 x D500 x H50 mm
-
・Accuracy: ± 0.5 mm
-
・Programming time: 240 min
-
・Processing time: 50 min/quantity
-
・Quantity: 1
-
・Material: Mild Steel (SGP)
-
・Thickness: 3.2 mm
-
・Type: Prototype
Process
CAD/CAM
Strengths
きちんとした格子になるように、各丸パイプの切り欠き寸法を調整する必要があり、上手く格子状になるように苦労しました。
