Sheet Metal Processing

Other Bending Machines

ES-3613

ES-3613

Pursue accuracy and user-friendliness
Ultimate AC servo driven bending machine

Minimum setting unit by AC servo motor & ball screw drive : D-axis 0.001mm. To achieve high speed・high accuracy processing.

Processing samples

Sample 1

Specifications



Capacity
(kN)

Bending length
(mm)

Stroke length
(mm)

Bending speed
(mm/s)

Mass of machine
(kg)

ES-3613

360

1300

100

0.2 - 20

3400

FBDⅢ-NT Series

FBDⅢ-NT Series

High-accuracy bending machines for network support

Processing samples

Sample 1Sample 2

Specifications



Capacity
(kN)

Bending length
(mm)

Stroke length
(mm)

Bending speed
(mm/s)
【50/60Hz】

Mass of machine
(kg)

FBDⅢ-5012NT

490

1200

150

8/9

3200

TBZ Series

TBZ Series

Ideal bending automation system for high productivity and cost reduction

Processing samples

Sample 1Sample 2

Specifications



Work-piece size
(Max.)
(mm)

Work-piece size
(Min.)
(mm)

Capacity
(kN)

L/UL
device

Programming

TBZ2523H

1250×2500×2.3

250×400×0.5

470

Manual L/UL or custom line

Easy programming by 2D mode

TBZ3023H

1525×3050×2.3

250×400×0.5

735

Custom line

*For Japan domestic market.
